Hot Sale Packaging Cardboard Thin Edge carbide slitter knives Cutting tools
Advantage of carbide slitter knife
A continuous production of buttons over 18 years
B total production quantity of buttons up to 800 tons
C widely exported to Europe,America,Australia, Brazil, India, Russia etc
D promise you the 100% raw material.
E We, Mingri CARBIDE, quotation your order with 24 hours
F We, Mingri CARBIDE , accept your order as per your requirements
Description of carbide slitter knife
| Name | carbide slitter knife |
| Feature | 1.HSS crton cutting knife 2.super sharpness and hardness HRC40-68 Precision: 0.02mm Thickness range: 0.1mm~6.0mm |
| Material | tungsten carbide |
| Usage | corrugating paperWood/Plastic/Food/Leather/Fabric/metallurgy etc |
| Service | OEM & ODM |
| Delivery | depend on the quantity |
| Packing | Heat-sealed plastic bag |
| Grade | Grain size | Density | T.R.S | Hardness | Suitable for cutting |
| g/cm3 | ≥ N/mm2 | HRA |
| MR020 | ultrafine grain | 14.5 | 3300 | 91.5±0.5 | domestic machine to cut corrugated board, chemical fiber,leather,sheet metal,battery |
| MR030 | ultrafine grain | 14.1 | 3500 | 90.5±0.5 | foreign machine to cut corrugated board |
| item | Common sizes OD*ID*T(mm) | Holes | Available for machine |
| 1 | Ø230*Ø110*1.1 | 6 holes*Ø9 | FOSBER |
| 2 | Ø230*Ø135*1.1 | 4 key slots | FOSBER |
| 3 | Ø220*Ø115*1 | 3 holes*Ø9 | AGNATI |
| 4 | Ø240*Ø32*1.2 | 2 holes*Ø8.5 | BHS |
| 5 | Ø240*Ø115*1 | 3 holes*Ø9 | AGNATI |
| 6 | Ø250*Ø150*0.8 | | PETERS |
| 7 | Ø257*Ø135*1.1 | | FOSBER |
| 8 | Ø260*Ø112*1.5 | 6 holes*Ø11 | ORANDA |
| 9 | Ø260*Ø140*1.5 | | ISOWA |
| 10 | Ø260*Ø168.3*1.2 | 8 holes*Ø10.5 | MARQUIP |
| 11 | Ø270*Ø168.3*1.5 | 8 holes*Ø10.5 | HSEIH |
| 12 | Ø270*Ø140*1.3 | 6 holes*Ø11 | VATANMAKEINA |
| 13 | Ø270*Ø170*1.3 | 8 holes*Ø10.5 | |
| 14 | Ø280*Ø160*1 | 6 holes*Ø7.5 | MITSUBISHI |
| 15 | Ø280*Ø202*1.4 | 6 holes*Ø8 | MITSUBISHI |
| 16 | Ø291*Ø203*1.1 | 6 holes*Ø8.5 | FOSBER |
| 17 | Ø300*Ø112*1.2 | 6 holes*Ø11 | TCY |
| Acceptable for customers' design |
Appllication of carbide corrugated paper blade
Packing and delivery of carbide corrugated paper blade
